KT7000C biometric Enabled Breath Analyzer
KT-7000C offers professional users precise and quick breath alcohol analysis in a user-friendly and compact form.
- Fingerprint Capacity: 120 finger prints for admin users
- Memory Stores 10 million measured values with biometric
- Android system: 7.1.2 with latest processing technology and comprehensive features.
- Camera: 8 megapixels camera capture photo of the subject
- Digital Signatures of testee and doctor
Description
KT-7000C offers professional users precise and quick breath alcohol analysis in a user-friendly and compact form.
Product Features
- Processor: high-performance Four-core processor
- Android system: 1.2 with latest processing technology and comprehensive features.
- UK made Electrochemical Fuel cell sensor: Highly specificity to alcohol, unaffected by other possible breath
- Display: 5 inch 480*854 Multi-touch capacitive Touch screen.
- Wireless network: 4G network (support td-lte, fdd-lte),
- Positioning function: support both GPS and BDS, indoor
- Camera: 8 megapixels camera capture photo of the
- Night vision function: with infrared light, intelligently open and close night vision function of
- Battery: removable 7V/4500mAh Recharge Li-ion battery.
- Number of Measurement per battery pack: More than 1000 tests.
- Memory: Data storage of more than 10 million test results/ storage memory: 8GB.
- Fingerprint: for device management, fingerprint collection and comparison (Option)
- Handwritten Signature: support handwritten police & subject
- Printer: built-in thermal printer
Technical Specifications
| Item | Technical Data | ||
|
Alcohol Testing |
Principle of measurement | Electrochemical Sensor, Alcohol-specific | |
| Measurement Range (BrAC) | 0mg/L-2.5mg/L (BrAC) | ||
| Resolution | 0.001mg/L | ||
|
Accuracy: Max. Measuring error, in relation to the ethanol standard |
Ethanol Vapor Concentration
C /(mg/L) |
Deviation |
|
| C≤2.000 | -0.040～0 mg/L Or -10%～0，whichever with the largest absolute value. | ||
| C＞2.000 | 0～-2×(C/2 -0.9)mg/L | ||
|
Repeatability |
Ethanol Vapor Concentration
C / (mg/L) |
Repeatability |
|
| C≤2.000 | 0.007mg/L Or 1.67%，whichever lager | ||
| C＞2.000 | 0～0.33×(C/2-0.9)mg/L | ||
| Calibration | Every 12 months | ||
| Temperature Range- operation | -10°C～50°C | ||
| Temperature
Range-storage |
-30°C～70°C | ||
|
Optimum Working Conditions |
Temperature: 45℃±5℃； Humidity:50%±30%；
Atmospheric pressure: ambient atmospheric pressure; No vapor or electromagnetic disturbances in the environment are influencing the normal working conditions of the device. |
||
| Memory | Stores 10 million measured values | ||
|
Basic configuration |
Processor | 4-core A35 1.3GHz | |
| Memory | Running memory: 1GB; storage memory: 8GB | ||
| System | Android 7.1.2 | ||
| LCD | 4.5inch 480*854 touch screen | ||
| PC Interface | Type-C | ||
| Input method | EN, Handwritten | ||
| Fingerprint | Capacity: 120 finger prints | ||
| Camera | 8 megapixels | ||
| Voice broadcast | Intelligent voice broadcast | ||
| Positioning | GPS & BDS (OPTIONAL) | ||
| Printer | Built-in thermal printer | ||
| Battery | 4500mAh/3.7V Lithium-ion-battery | ||
| Operation Voltage | State of charging | State of operation | |
| DC4.2V | DC3.6~4.2V | ||
| Weight | Approx. 420g（including printer, battery） | ||
| Dimension | 200mm（L）×81mm（W）×33mm（H） | ||
| Communication | 4G, WIFI, Bluetooth | ||
Download Brochure
WATCH kt7000c DEMO
biometric enabled breath analyzer demo
